Description
This microscope has an innovative stand structure, clear specimen observation, and convenient operation. It is specially designed for cell culture observation.
Features
- Excellent optical function with infinitive optical system.
- WithLWD infinitive plan objective making viewing field flatter and brighter, contrast sharper, living cell observing easier.
- With pre-centerable phase annulus, available to observe low contrast or transparentspecimen.
- Advanced and reliable mechanicalstage with knob height and tightness adjustable.
- Different holders for various observations.
Specifications
Model MSC-IV100Y Optics Infinite optical system Observation Tube Tilting trinocular, interpupillary 48-75mm Viewing Head Seidentopf head, inclined at 30° Eyepiece High eye point, extra wide field eyepiece EW10X/22 Objective LWD Infinitive Plan Objective 4X/0.1 WD 17.3mm 40X/0.6 WD 2.1mm *10X/0.25 WD 10mm *20X/0.4 WD 5.1mm Infinitive Plan Phase Objective PH10X/0.25 WD 10mm PH20X/0.4 WD 5.1mm *PH40X/0.6 WD 2.1mm Nosepiece Quintuple nosepiece Stage Plain stage 160X250mm Glass insert Auxiliary stages 70X180mm *Attachable mechanical stage, X-Y coaxial control, Moving range 120X78mm *Terasaki holder *φ35mm Petri dish holder *φ54mm Slide glass holder *φ90mm Petri dish holder Condenser WLWD Condenser NA0.3, LWD72mm (without condenser 150mm)
*Centering Telescope Centering telescope(φ30mm) Phase Annulus 10X-20X, 40X Phase annulus plate *10X-20X, 40X Phase annulus plate(Center adjustable) Focusing Coaxial coarse and fine adjustment, Vertical objective movement Coarse stroke: 37.7mm per rotation, Fine stroke: 0.2mm per rotation
Illumination 6V 30W Halogen lamp Filter Diameter 45mm, blue, green and ground glass *Optional Photo attachment, video adapter with C mount, inverted fluorescent attachment *Optional configuration
-
