CO2 Incubator, ICB-CO2-H Series, ICB-CO2-W Series

  • CO2 Incubator, ICB-CO2-H Series, ICB-CO2-W Series
商品圖像
  • 商品資訊

    Description

    Application
    CO2 Incubator is widely used in modern medicine, biology, chemistry and agriculture science for the culture of biological cells, tissues and bacterial.
    Features
    Faster CO2 concentration restoration speed
    If the door needs to be opened frequently during the experiment, infrared sensors are the best choice.
    The infrared (IR) sensor has the characteristics of fast monitoring of carbon dioxide gas and is not affected by fluctuations in external temperature and humidity.
    Internal circulation system
    Adopts high-quality fan, higher ventilation efficiency and better temperature uniformity.
    The circulation fan speed can be automatically controlled.
    High cleanliness level
    The door temperature controller can effectively prevent condensation on the glass door of the incubator and prevent the possibility of microbial contamination caused by condensation water from the glass door.
    The CO2 air inlet is equipped with a high-efficiency microbial filter. For particles with a diameter of 0.3μm or greater, the filtration efficiency is as high as 99.99%, effectively filtering bacteria and dust particles in CO2 gas.
    With UV sterilization system that can regularly disinfect the inside of chamber.
    Humanized design
    Two-layer stacking makes full use of laboratory space.
    Microcomputer LCD controller, precise and reliable control.
    The stainless steel chamber and shelves have semi-circular arc transitions at the four corners, and the shelves brackets can be freely assembled and removed for easy cleaning.

    Safety
    Independent temperature limit alarm system (optional) to ensure safe operation of the experiment.
    Low temperature, high temperature and over-temperature alarms.
    Alarm for long door opening time.

    Specifications

    Model ICB-CO2-50H ICB-CO2-80H ICB-CO2-150H ICB-CO2-190H ICB-CO2-240H ICB-CO2-30W ICB-CO2-80W ICB-CO2-150W
    Capacity(L) 50/80 150/190 240 26/80 150
    Circulation Mode Forced convection
    Dimension



    (W*D*H)

    Internal (mm) 400*350*350



    400*450*500

    480*530*610



    520*530*690

    600*630*670 290*290*310



    400*400*500

    500*500*650
    External (mm) 580*450*730



    590*657*870

    670*710*950



    708*710*1030

    788*837*940 440*410*544



    550*520*764

    650*615*914
    Temperature Range (℃) RT.+5~55
    Fluctuation (℃) ±0.2 ±0.1
    Resolution (℃) ±0.1
    Uniformity (℃) ±0.3°C
    Recovery (Door open 30s, recovery to 37℃ ≤ 8min
    Humidity Range ≥90%
    Method Natural vaporization
    CO2 Range 0~20%
    Resolution +0.1%
    Sensor IR sensor
    Recovery (Door open 30s, recovery to 5%)≤3min
    Heating Method Air-jacketed, PID Control Water-jacketed,  PID Control
    Display LCD
    Material Internal 304 Stainless steel
    External Cold rolled steel
    Shelves(Standard / Max ) 2/4 3/6 3/6 2/4 3/6
    Test Hole (mm) φ25
    Safety Device Low temperature, high temperature and over-temperature alarms,



    Alarm for long door opening time

    Sterilization Method UV Sterilization
    Electricity Voltage/



    Frequency

    AC 220/110V, 50/60Hz
    Consumption (W) 450/500 750 950 250/680 950
    N.W./G.W. (kg) 59/79



    64/98

    83/126



    85/134

    95/148 50/65



    55/90

    68/125
    Shipping Dimension



    (W*D*H) (mm)

    830*800*980



    740*700*1040

    830*840*1250 930*910*1220 560*800*540



    700*670*1010

    830*780*1070
    Optional 1. RS485 interface and communication software



    2. Special CO2 pressure reducing valve

    3. Humidity display system

    4.Independent temperature limiting controller

    5.Printer (Nested)

    6.HEPA high efficiency filter
