Climate Chamber, ICB-CC250H/CC350H

  • Climate Chamber, ICB-CC250H/CC350H
商品圖像
  • 商品資訊

    Description

    Applications
    It is widely used in microbial tissue and cell culture, seed germination, seedling raising test, plant cultivation, insect and small animal feeding, etc. Different environmental and climatic conditions can be accurately simulated.

    Features
    Energy saving
    Imported compressor, safe and reliable.
    Defrosting function: three-stage electric heating defrosting program control.
    Adopts energy-saving LED cold light source;The light intensity is adjustable in six levels to meet plants with different light needs.
    Intelligent control of humidification method instrument.

    Intelligent control
    Large high efinition LCD display,with intelligent microcomputer control, parameter real-time display.
    The intelligent temperature control system can continuously control temperature, light level and running time.

    Internal circulation system
    Back suction and bottom forced convection system.
    Adopts high-quality fan and large impeller fan, the machine has higher ventilation efficiency and better temperature uniformity.
    The shelf is laser hollowed out with round holes for better ventilation and better temperature uniformity.

    Dedicated sheet metal processing
    The shelf can be disassembled and can be freely adjusted up and down, with a minimum spacing of 30mm.
    The inner chamber is made of high-quality brushed stainless steel, with strong corrosion resistance.

    Humanized design
    Built-in observation window to make the objects in the chamber clear at a glance.
    Safety
    Equipped with leakage protection device to ensure the safety of operators and other equipment in the laboratory.
    Digital independent temperature limiter control sound and light alarm system.
    Self-diagnosis function: display fault information, which is convenient for judging the fault point.

    Optional
    Test hole, internal socket, Digital independent temperature limiter
    、Programmable temperature controller (Optional USB,RS485/232 and built-in printer)、Spare shelf

    Specifications

    Model ICB-CC250H ICB-CC350H
    Capacity(L) 250 350
    Circulation Mode Forced  convection
    Dimension(W*D*H) Internal (mm) 560*420*1050 560*530*1200
    External (mm) 660*660*1700 670*730*1880
    Temperature Range (℃) With lighting:10~50 ; Without lighting:4~50
    Fluctuation (℃) ±1
    Resolution (℃) 0.1
    Uniformity (℃) ±1 ±2
    Sensor PT100
    Humidity Range 50~90%RH
    Stability ±5 ~ ±7 %
    Method Internal
    Sensor High precision anti-condensation
    Illumination(Lx) 0~12000 0~15000
    Illumination Control 6-level relative illuminance control
    Controller PID
    Display Large high efinition LCD
    Timer 1~9999min (Optional 30*segments*100cycles)
    Material Internal  Stainless steel
    External Cold rolled steel electrostatic spraying exterior
    Shelves 3
    Test Hole (Optional)  Φ 25,50,80,100mm
    Internal Socket Optional
    Refrigerant R134a (CFC free)
    Defrosting Mode Automatic
    Safety Device Visible& Audible over temperaure, over humidity, water shortage  alarm ;leakage protector
    Electricity Voltage/Frequency AC 220/110V, 50/60Hz
    Consumption (W) 1500 2150
    N.W./G.W. (kg) 120 / 128 155 / 260
    Package Dimension(W*D*H) (mm) 810*770*1900 900*940*2080
    Optional Test hole, internal socket, Digital independent temperature limiter
    、Programable temperature controller (Optional USB,RS485/232 and  built-in printer)、Spare shelf
