Forced Air Drying Oven, DOF-V420-V900 AB Series

  • Forced Air Drying Oven, DOF-V420-V900 AB Series
  • Forced Air Drying Oven, DOF-V420-V900 AB Series
  • Forced Air Drying Oven, DOF-V420-V900 AB Series
  • Forced Air Drying Oven, DOF-V420-V900 AB Series
商品圖像

  • 商品資訊

    Description

    It is widely used in chemical industry, electronic communication, plastics, cables, electroplating, hardware, automobile, optoelectronics, rubber products, molds, spraying, printing, medical treatment, aerospace and universities and other industries.

    Features

    Energy saving

    • The sealing ring of incubator adopts a new type of synthetic silicone sealing strip, which effectively prevents heat loss.
    • Automatically adjust the control parameters according to the ambient temperature and load to achieve the optimal heating method and reduce energy consumption.
    • High efficiency and energy saving compressor, stable temperature control and low power consumption.

    Intelligent LCD control

    • Large-screen LCD display, real-time display of parameters, self-locking function of screen, simple and convenient operation.
    • Menu-type operation interface, simple and convenient operation, can quickly set temperature and time parameters.
    • Running function: fixed value running, timing running; The screen will display “END” with a beeping reminder after the running time is completed.

    Internal circulation system

    • Adopts high-quality fan and large impeller fan, the machine has higher ventilation efficiency and better temperature uniformity.
    • The circulation system adopts the back suction and the bottom vertical air supply mode.
    • The shelf is laser hollowed out with round holes for better ventilation and better temperature uniformity.

    Dedicated sheet metal processing

    • The shelf can be disassembled and can be freely adjusted up and down, with a minimum spacing of 30mm.
    • The inner tank is made of high-quality brushed stainless steel, with strong corrosion resistance.
    • Built in observation window to make the objects in the chamber clear at a glance.
    • The anti-scalding design of the door handle makes it easy to open and close the door.

    Safety

    • Equipped with leakage protection device to ensure the safety of operators and other equipment in the laboratory.
    • With limited temperature control sound and light alarm system.
    • Self-diagnosis function: display fault information, which is convenient for judging the fault point.

    Specifications

    Model DOF-V420A
    DOF-V420B    		 DOF-V600A
    DOF-V600B    		 DOF-V900A
    DOF-V900B
    Capacity(L) 420 600 900
    Circulation Forced air convection
    Dimension(W*D*H) Internal(mm) 600*550*1300 800*600*1300 1000*600*1600
      External(mm) 750*730*1700 950*780*1720 1140*800*2150
    Temperature Range(℃) RT+10-250



    RT+10-300
    Fluctuation (℃) ±0.5
    Resolution (℃) ±0.1
    Uniformity(℃) 25%
    Sensor PT100
    Controller PID
    Display LCD
    Timer(min) 1-9999
    Material Internal Stainless steel
    External Electro-galvanized steel with antimicrobial powder coating
    Shelves 3pcs 4pcs 4pcs
    Test Hole Optional φ25,50,80mm
    Safety Device Leakage protector/Over- temperature alarm
    Electricity Voltage/Frequency(V/Hz) 380/50 380/50 380/50
    Consumption (W) 4000
    4500    		 4500
    5000    		 6000
    6500
    N. W./G.W.(kg) 120/145 145/170 195/230
    Shipping Dimension (W*D*H) (mm) 870*860*1830 1080*910*1880 910*1260*2200
    Optional 1.Independent temperature limiting controller
    2.Intelligent LCD procedure temperature controller (Optional USB,RS485/232 and printer)
