Description
Description
This product adopts four channel and double 16-well blocks, which can run two different files simultaneously. The product combines a variety of advanced technologies. 7-inch high-definition TFT color touch screen, Win10 operating system with analysis software, complete quantitative analysis and printing report without computer. It adopts American Marlow custom-made peltier, high sensitivity photoelectric detector and side scan technology, to ensure superior performance and stable detection results.
Advantages
- Four channels and double 16-well blocks design, can run two different programs at the same.
- Small size, light weight, easy to carry.
- Powerful software analysis function, which can be used for Quantitative Analysis, Melting Curve Analysis, Genotyping, 7-inch high-definition TFT color touch screen, and embedded Win 10 operating system.
- 20G flash memory can save 40，000 experimental data.
- Printer as an optional which can print the records directly, no need to connect the computer.
- Imported 32 bundled optical fibers are used to collect fluorescence from the side to increase the intensity of fluorescence signal and reduce light conduction damage.
- Black reaction block to avoid background noise.
- LED light source has the advantage of energy saving, environmental protection, long service life and maintenance free.
- The electromagnetic lock cover technology prevents the hot lid from accidentally opening.
- Front shutdown button makes file data more secure.
- Constant current control circuit makes power output smooth and extends Peltier life, also improves temperature control accuracy. It has the protection functions of over-current, over temperature, power-off data self recovery.
- Forward and backward air vent design, can be placed side byside, saving space.
Specifications
Model PCR-Q32-4F PCR-Q32-4 Sample Capacity 32×0.2ml(4×8well, dual block) Consumable Clear 0.2 ml PCR tube /8-tube strips Reaction Volume 15-100μL Temperature control technology Marlow customized Peltier allow 1,000,000 cycles Temperature Range 0-100℃ (Resolution: 0.1℃) MAX. Ramp Rate 8℃/s 5℃/s Temperature fluctuation ±0.1℃ Uniformity ±0.25℃ Accuracy ±0.25℃ Hot Lid Temperature 30-110℃((Adjustable, default 105℃)) Temperature Control Block/Tube Excitation Wavelength 460—628nm Emission Wavelength F1: 520-540nm F2: 540-580nm F3: 571-612nm F4: 628-692nm Factory Calibrated Dyes F1: FAM/SYBR Green I, F2: HEX/VIC/JOE/TET, F3: ROX, F4: CY5 Excitation Long life LED Detection High sensitivity photoelectric detector Dynamic Range 1-1010 Copies Sensitivity 1 copy Feature function Quantitative/qualitative analysis, Melting curve, Genotyping Date Export Formats Excel, CSV, Txt Printing Report can be printed (optional USB thermal printer) Control Method 7 inch color TFT touch screen, Can be connected to computer control Communication USB2.0 Dimension (L×W×H) 300×267×198mm Net Weight 11Kg 8 Kg Electricity 220VAC, 50Hz; DC29V 600W 220VAC, 50Hz; DC15V 255W -
