Gradient PCR Machine, PCRTC-G

Description

DESCRIPTION

Reliable heating/cooling elements and precise temperature control
Unique design of block ensures the temperature uniformity and repeatable results
7 inch Large color touch panel screen for easy programming withfriendly software
High performance DSP and temperature control
Fast heating and cooling rate
Largeprogram storage

7 inch Large color touch panel screen

It is for easy programming withfriendly software

Long lasting peltier, precise temperature control by zone

Compatible with common tubes of different heights

Eight rows of tubes and 96-well plates

SPECIFICATIONS

Specifications	PCRTC-G
Sample Capacity	96X0.2mL PCR tube, 8X12 PCR plate or 96 well plate
Heating Temperature Range	4-105℃
Lid Temperature Range	30-110℃
Temperature Display Accuracy	±0.1℃
Temperature Control Accuracy [at 55℃]	±0.3℃
Temperature uniformity[at 55℃]	<0.3℃
Max. Heating/Cooling Rate	5℃/Sec
Gradient Temperature Setting Range	30-99℃
Gradient Range	1-42℃
Adapter block material	aluminum
Display	7” LCD 800×480
Input	Touch panel
User defined file system	Max. 30 segments 99 cycles max. 16 folder and 16 files each folder
Power off protection	Yes
Power Supply	100-120V/200-240V,50/60Hz
Dimension [D×W×H]	590x420x430 mm
Gross/Net	13kg / 12kg
